Lead Hardware Engineer, Starsky RoboticsNeed a Circuit Board?
Benefits of A.I. Driven Design
We augment our human designers with state-of-the-art artificial intelligence and optimization algorithms to design your board faster and cheaper.
How we've helped our customers
Delivered on projects 3X faster than competing design services, cutting our client's time-to-market.
Designed and delivered highly reliable hardware, resolving previous issues with noisy sensors and power integrity.
Achieved the maximum performance per dollar for power distribution boards through massive optimization.
Pricing
Adapters
Custom PCBs that route signals from one connector to another.
$499 / design
Designed in:
24 Hours
- Max Connectors: 5
- Max Pins: 250
- Highest Frequency: 500MHz
- Max Current per net: 10A
Automated Service
We can create high-certainty designs fast.
$3k / design
Designed in:
24 Hours
- Key components already chosen
- Number of components: < 50
- Number of unique components: < 20
- Number of pins: < 250
- Highest current net: < 3A
- Highest frequency: < 500MHz
- Total power: < 20W
Augmented Service
We can do a lot, and that's hard to capture in 3 categories.
- For everything else we’ll do a custom quote, and use our software to cut cost and schedule. Click the button below to send us a confidential project intake form.
Frequently Asked Questions
How does this work?
We work with you directly to figure out the requirements and best solution for your product, then use our own tools to design the circuit board. We prototype it, test it, and then give you a full design package with functioning prototype, CAD files, documentation, and example code. Think of us as an electrical engineering team you can run in the cloud.
Are you just running an autorouter for us?
No. There are too many design considerations for an autorouter to work well: such as component placements, processor pin mapping, and power and signal integrity constraints. Instead, we augment our human designers with state-of-the-art A.I. tools to ensure we produce high quality boards.
What are the inputs to your PCB design service?
The input is a high-level system block diagram (which could be on the back of a napkin), and a description of the required functionality. We work with you to hammer out the details and then work your design through our tools.
What are the outputs of your PCB design service?
The design package we give you has native CAD files (KiCAD right now, we may write other exporters), Gerbers, Bill of materials, and datasheets for all components. We also prototype the design so another output is a functioning board.
Do you do any firmware writing in addition to board design?
Yes, we write the low-level device driver code along with example code showing how to operate all the peripherals on the PCB. With that, you can start coding your app right away.
Does JITX make the boards, or do we take the files to a third party to get them made?
We always make at least one board to validate and characterize the design. We also help you coordinate pilot manufacturing runs of 50-250 devices, and you can contact us if you need more than that.
